49
6-4-7. Troubleshooting Flowchart
Check the
rotation of
compressor.
Check the
hot air inlet.
The air is
warm.
The air is
not warm.
Leakage of
refrigerant
Normal
The air is a
little cold.
Cycle
clogged
LEV mal-
function
Leakage on
splice
Leakage on
radiator
Moisture not pro-
vided
LEV malfunction
Capillary tube
clogged
Valve housing
not inserted
Min IPW8 housing
not inserted
Valve L/Wire
disconnected
Valve failure
Check the
leakage.
