12-21. Problem with Wrinkle Removal #1
Did you use the hanger supplied with the product?
Is the thickness of the hanger hook 4 mm or below?
Explain to the customer the precautions when using a
commercially available hanger.
Check if there is any faulty component.
Check if there is any faulty component.
0. First thing you need to check
Is the steam outlet clogged when you open the door?
Are the hoses in the machine room properly assembled without bending/
misassembly?
Is the resistance on the AG heater approx. 28 ohm?
Check if the heater wiring is disconnected.
Replace the main PCB.
Remove clothing or foreign substances and check
again.
Replace the AG.
Assemble the hose properly. If
necessary, replace the hose.
Replace the AG.
1. Check if the steam functions properly.
Does the moving hanger function properly in the Test
mode?
Is the V-belt properly assembled?
Is the motor connector properly assembled?
Is the roller of the hanger ASM (B) properly assembled?
Assemble the V-belt properly and check
again.
Connect the connector.
Assemble the hanger ASM(B) properly
and check again.
2. Check if the moving hanger functions properly.
YES
YES
NO
NO
YES
NO
NO
NO
NO
YES
YES
YES
NO
NO
NO
YES NO
YES
YES
To Next Page
