13
EN
Connecting the Supply Hose
• Before connecting the water supply hose to
the water tap, check the hose type and then
choose the correct instruction.
• The water supply hose supplied may vary
from country to country. Make sure to connect
the blue supply hose to the COLD water tap,
and the orange supply hose to the HOT water
tap.
• Water supply pressure must be between 30
kPa and 800 kPa (0.3 - 8.0 kgf / cm²).
• Do not overtighten the water supply hose.
• If the water supply pressure is more than 800
kPa, a decompression device should be
installed.
• Periodically check the condition of the hose
and replace the hose if necessary.
Checking the Rubber Seal on the
Supply Hose
Two rubber seals are supplied with the water
supply hoses. They are used for preventing
water leaks. Make sure the connection to taps
is sufficiently tight.
Hose connector
Rubber seal
Hose connector
Rubber seal
Connecting Hose to Water Tap
Connecting Screw-Type Hose to Tap
with Thread
Screw the hose connector onto the water
supply tap.
Connecting Screw-Type Hose to Tap
Without Thread
1
Loose the four fixing screws.
Upper
connector
Rubber
seal
Fixing screw
2
Remove the guide plate if the tap is too
large to fit the adapter.
Guide plate
To Next Page
