33
DIASSEMBLY INSTRUCTIONS
11
1. Disassemble Nut by grasping the edge
of left motor shaft at the same time.
2. Disassemble Heater Housing by
detaching inner Connector harness and
unscrewing.
3. Disassemble Heater by unscrewing 2
screws.
HOUSING
HEATER
