LG TX - Page 46

45
■ 1020 Keyboard
1. Remove 2 screws.
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010)
2M2.0 x L5.01SZZBA4122A1
QtySpecificationFRU No.No.
2. To remove 4 hooks, insert a (-) type screwdriver into a hook located at the upper end of keyboard, and
pull it up.
Ch5. Removing and replacing a part
