LG TX - Page 54

53
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. Keyboard(1020) c. WLAN Card(1030) d. MDC Card(1040)
e. Micro DIMM(1050) f. Keydeck(1060)
■ 1070 DMB Module
1. Remove 4 screws, then remove 2 plates.
4M2.0 x L3.01SZZBA4017E1
QtySpecificationFRU No.No.
Ch5. Removing and replacing a part
