60
■ 1100 Fan Assembly
1. Remove 4 or 6 screws, then disconnect the Fan Assembly Connector.
(GM: 4 screws, PM: 6 screws)
6M2.0 x L3.01SZZBA4017E1
QtySpecificationFRU No.No.
2. Remove the Fan Assembly.
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. Keyboard(1020) c. WLAN Card(1030) d. MDC Card(1040)
e. Micro DIMM(1050) f. Keydeck(1060) g. DMB Module(1070) h. Display Module(1080)
i. HDD(1090)
Ch5. Removing and replacing a part
