M
K
VACUUM CLEANER
SERVICE MANUAL
CAUTION
BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS"
IN THIS MANUAL.
MODELS : V-3300/D/L/T/TG/TY/DV, V-3310/D/L/T, V-3340/D/T, V-3314/D/T,
TURBO/2700/2800/2900/2950/3300/3300R/3400/3100/3100B/33RS,
V-3312, V-3333, 3310R, AP1300, EM-1300, EV3300, VC-2550,
HL7122, VX-330, SWEEFTY/E, V-C3345ST, V-C3343ND, V-C3333SB
M
K

Questions and Answers

  • A
    Antonio WalkerAug 5, 2025
    Why does my LG V-3300T Vacuum Cleaner have weak suction power?
    • G
      George MasonAug 5, 2025
      If your LG Vacuum Cleaner exhibits weak suction power, several factors could be responsible. Check for blockages in the hose and extension wands and remove any foreign materials. Ensure that the slide knob on the handle is closed. Other potential causes include a defaced carbon brush or a cut motor armature, in which case you should exchange the carbon brush or the motor. If foreign matters are attached to the impeller, remove them. Note that low voltage can also cause weak suction; in this case, you should inquire with your power utility company. If the motor turns normally, but suction power is weak, remove any foreign matters or exchange the filter bag or clean the cloth bag.
  • K
    Kathleen FrancisAug 9, 2025
    How to fix vibration noises in my LG V-3300T Vacuum Cleaner?
    • A
      Austin SanchezAug 9, 2025
      If your LG Vacuum Cleaner is making unusual vibration noises, start by checking for loose parts and secure them firmly. If the motor assembly is unbalanced, you may need to exchange or repair the motor. Also, check the impeller and armature for any attached foreign matters and remove them. Poor carbon brush rectification or a cut armature can also cause vibration noises, requiring replacement of the carbon brush or motor, or removal of any foreign matter.
  • R
    Robert HesterAug 13, 2025
    How to fix improper hose or nozzle connection on my LG V-3300T Vacuum Cleaner?
    • S
      Sharon CraigAug 13, 2025
      If you're experiencing an improper hose or nozzle connection with your LG Vacuum Cleaner, it could be due to bent connection parts, which would need to be exchanged. Another cause could be a poor connection due to foreign matters; remove any obstructions and reconnect.
  • G
    garrett75Aug 17, 2025
    What to do if my LG V-3300T switch is on, but the motor doesn't turn?
    • A
      alexandracarrilloAug 17, 2025
      If your LG Vacuum Cleaner is switched on but the motor does not turn, several issues could be the cause. First, check the fuse in the coverknife switch and exchange it if it has melted down. Ensure the plug is properly inserted. A cut power cord or interior lead wire will require repair or exchange. Motor coil damage necessitates motor replacement. Poor contact or a defaced carbon brush requires brush exchange or repair. Finally, a poor switch contact point will require switch replacement.
  • M
    Matthew CrawfordAug 22, 2025
    Why does my LG Vacuum Cleaner cause radio, TV reception disturbance?
    • R
      Rachel RitterAug 22, 2025
      If your LG Vacuum Cleaner is causing radio or TV reception disturbance, the issue may stem from a poor cord or lead wire, which should be exchanged. Alternatively, poor carbon brush rectification could be the cause, necessitating the exchange of the carbon brush or the motor. A faulty electric connector or receiver should be repaired, while a poor capacitor should be exchanged.
  • J
    Jeremy SmithAug 26, 2025
    What to do if my LG Vacuum Cleaner motor buzzes but doesn't turn on?
    • C
      csolomonAug 27, 2025
      If your LG Vacuum Cleaner is switched on, but the motor buzzes without turning, this could be due to several reasons. The motor armature might be cut, requiring you to exchange the motor. Another possibility is ball bearing defacement, which also necessitates motor replacement. Lastly, the impeller might be hindered by foreign matters. In this case, you should remove any foreign objects.
  • R
    rjohnstonAug 30, 2025
    Why does my LG V-3300T motor turns when switched off?
    • D
      douglasriversAug 30, 2025
      If your LG Vacuum Cleaner motor turns when switched off, it may be due to a poor connection, which should be repaired. Alternatively, the switch itself may be faulty and require replacement.

Summary

Safety Precautions

Change the paper bag or clean the cloth bag

Replace or clean the dust bag when the indicator turns red for optimal suction power.

Filter Maintenance

Never use the vacuum without filters. Wash cloth, clean, and exhaust filters with neutral cleanser.

Dust Indicator

The dust indicator turns red when the filter is full, signaling a need for replacement or cleaning.

Materials to Avoid Suction

Do not suction liquids, flammable substances, burning objects, bulky, or sharp items.

Attachment Usage

Use nozzles for floors and crevices. Limit crevice tool use to prevent motor damage.

Servicing Precautions

Specifications

Vacuum Cleaner Features

Disassembly Instructions Part 1

Disassembly Instructions Part 2

Trouble Shooting Guide Part 1

Motor Does Not Turn On

Diagnoses for motor failure: check power source, plug, cord, fuse, motor, or switch contacts.

Motor Does Not Turn But Buzzes

Troubleshooting for buzzing motor: check armature, bearings, or impeller for hindrances.

Trouble Shooting Guide Part 2

Motor Turns Off But Continues Running

Addresses issues where the motor runs after being switched off, possibly due to connection or switch faults.

Weak Suction Power

Diagnoses for reduced suction: check brushes, motor, blockages, or low voltage.

Trouble Shooting Guide Part 3

Vibration Noises

Troubleshooting excessive vibration: secure loose parts, check motor assembly, or foreign matters.

Radio;TV Reception Disturbance

Addresses interference issues: check power cord, carbon brush, connectors, or capacitors.

Improper Hose or Nozzle Connection

Fixes for connection problems: straighten bent parts or clear foreign matters.

Block Diagram

Schematic Diagram

Printed Circuit Diagram

Block Diagram (Alternative Models)

Schematic Diagram (Alternative Models)

Printed Circuit Diagram (Alternative Models)

Exploded View: Base Assembly and Body

Exploded View: Cover Assembly and Body

Exploded View: Hose and Nozzle Assemblies

Exploded View: Accessory Assembly

Replacement Parts List Part 1

Replacement Parts List Part 2
