LG V-3310D User Manual

24 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

M

K

VACUUM CLEANER

SERVICE MANUAL

CAUTION

BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS"

IN THIS MANUAL.

MODELS : V-3300/D/L/T/TG/TY/DV, V-3310/D/L/T, V-3340/D/T, V-3314/D/T,

TURBO/2700/2800/2900/2950/3300/3300R/3400/3100/3100B/33RS,

V-3312, V-3333, 3310R, AP1300, EM-1300, EV3300, VC-2550,

HL7122, VX-330, SWEEFTY/E, V-C3345ST, V-C3343ND, V-C3333SB

M

K

Table of Contents

Questions and Answers:

H
Hunter NelsonAug 5, 2025
Why does my LG V-3310D Vacuum Cleaner have weak suction power?
- K
  kstaffordAug 5, 2025
  If your LG Vacuum Cleaner exhibits weak suction power, several factors could be responsible. Check for blockages in the hose and extension wands and remove any foreign materials. Ensure that the slide knob on the handle is closed. Other potential causes include a defaced carbon brush or a cut motor armature, in which case you should exchange the carbon brush or the motor. If foreign matters are attached to the impeller, remove them. Note that low voltage can also cause weak suction; in this case, you should inquire with your power utility company. If the motor turns normally, but suction power is weak, remove any foreign matters or exchange the filter bag or clean the cloth bag.
M
Matthew SuttonAug 9, 2025
How to fix vibration noises in my LG V-3310D Vacuum Cleaner?
- M
  Monica OlsonAug 9, 2025
  If your LG Vacuum Cleaner is making unusual vibration noises, start by checking for loose parts and secure them firmly. If the motor assembly is unbalanced, you may need to exchange or repair the motor. Also, check the impeller and armature for any attached foreign matters and remove them. Poor carbon brush rectification or a cut armature can also cause vibration noises, requiring replacement of the carbon brush or motor, or removal of any foreign matter.
J
Jamie JohnsonAug 13, 2025
How to fix improper hose or nozzle connection on my LG V-3310D Vacuum Cleaner?
- J
  Jeffrey MaldonadoAug 13, 2025
  If you're experiencing an improper hose or nozzle connection with your LG Vacuum Cleaner, it could be due to bent connection parts, which would need to be exchanged. Another cause could be a poor connection due to foreign matters; remove any obstructions and reconnect.
D
Dustin DavisAug 17, 2025
What to do if my LG Vacuum Cleaner switch is on, but the motor doesn't turn?
- T
  tracey42Aug 17, 2025
  If your LG Vacuum Cleaner is switched on but the motor does not turn, several issues could be the cause. First, check the fuse in the coverknife switch and exchange it if it has melted down. Ensure the plug is properly inserted. A cut power cord or interior lead wire will require repair or exchange. Motor coil damage necessitates motor replacement. Poor contact or a defaced carbon brush requires brush exchange or repair. Finally, a poor switch contact point will require switch replacement.
J
Jesus LynnAug 22, 2025
Why does my LG V-3310D cause radio, TV reception disturbance?
- M
  Michael MartinAug 22, 2025
  If your LG Vacuum Cleaner is causing radio or TV reception disturbance, the issue may stem from a poor cord or lead wire, which should be exchanged. Alternatively, poor carbon brush rectification could be the cause, necessitating the exchange of the carbon brush or the motor. A faulty electric connector or receiver should be repaired, while a poor capacitor should be exchanged.
E
Edward MasseyAug 26, 2025
What to do if my LG V-3310D Vacuum Cleaner motor buzzes but doesn't turn on?
- P
  Paul EdwardsAug 27, 2025
  If your LG Vacuum Cleaner is switched on, but the motor buzzes without turning, this could be due to several reasons. The motor armature might be cut, requiring you to exchange the motor. Another possibility is ball bearing defacement, which also necessitates motor replacement. Lastly, the impeller might be hindered by foreign matters. In this case, you should remove any foreign objects.
A
Anna SchmidtAug 30, 2025
Why does my LG Vacuum Cleaner motor turns when switched off?
- J
  joseph37Aug 30, 2025
  If your LG Vacuum Cleaner motor turns when switched off, it may be due to a poor connection, which should be repaired. Alternatively, the switch itself may be faulty and require replacement.
