17
Full charging
(Under charging)
In the case of not
existing an area to
be cleaned
In the case of
existing an area to
be cleaned
The status indication lamp while
robot is charged.
( In spatial expand mode)
High Middle Low Charging is
required
Flickering
※ If there is still an area to be cleaned and it returned to the home sta-
tion for recharging, the cleaning mode indicator will be displayed.
- When the battery is fully recharged, it cleans the area that is yet
cleaned.
-
If the cleaning mode indicator is lit during charging, pressing the
‘START’ button of the remote controller or ‘START/STOP’ button of
the HOM-BOT will search the un-cleaned area and start the cleaning.
- Pressing the mode selection button on the remote, (ZIGZAG, Cell by
Cell) will start the cleaning from the beginning.
HOW TO CHARGE THE BATTERY
Check 1. If the battery is not charging even when the HOM-BOT is at-
tached to the home station, check the following items.
- Turn the power switch on the bottom of the HOM-BOT off
once and then on again.
- Unplug and plug in the power plug on the home station.
- Wipe the terminal on the home station with a dry cloth.
Check 2. If the battery is still not charging after the previous check, try
the following.
- Attach the HOM-BOT to the home station.
-
Press the reset button at the rear of the home station for
three seconds.
If the Battery is Not Charging
The remaining battery charge can be confirmed from the charge indication lights, which will indicate charge
as follows:
• During charging, the charge remaining indication lights will flicker.
• When charging is completed at the home station, only the battery icon will illuminate to save power.
• The battery icon will flicker when battery charging is required.
Remaining Battery Charge Indicator
ENGLISH
