LG Electronics Inc.
VX8560
Test point
Test point
1
TP1
L606
+1.2V_DSP_CORE
TP2
C636
+2.6V_DSP_SDRAM
TP3
C641
+2.6V_DSP_IO
XW[VYZ\
104/235
