LG VX8560 - Main PCB Part List

LG Electronics Inc.
VX8560
5-1. Main PCB Part List
5-1. Main PCB Part List
Ref No Part NamePart Number Spec. Maker P/N
ANT1 03 ANTENNA,MOBI LE , FIXE D S NMF0036001 4 ,-6 dB,Internal, Bluetooth, SMD, Pb Free ,; ,SINGLE , , , ACS2450HBAVX88
ANT600 CONNECTOR,ETC ENZY0020001 PIN,2.5 mm,ETC , ,L=3.4, W=2.5, T=2.5 25SMT-4442-03
C1 0 0 CAP ,CHIP, MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C10 7 CA P ,CE RA MIC,CHIP ECCH0009203 33 nF,6.3V ,K ,X5R ,TC ,0603 , R/TP GRM033R60J333K
C1 0 8 CAP ,CHIP, MAKER ECZH0004402 100000 pF,16V ,Z ,X7R ,TC ,1005 ,R/TP MCH15 3C1 04 ZK
C10 9 CA P ,CE RA MIC,CHIP ECCH0009106 10 nF,16V ,K ,X7R ,TC ,0603 ,R/TP C0603X7R1C103KT
C11 0 CA P ,CE RA MIC,CHIP ECCH0000122 47 pF,50V,J, NP0,TC,1005, R/TP MCH155A470JK
C1 1 1 CAP ,CHIP, MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C11 2 CA P ,CE RA MIC,CHIP ECCH0001001 6.8 pF, 50V ,C ,NP0 , TC ,1005 , R/TP C1005COG1H6R8DT
C113 INDUCTOR,CHIP ELCH0004718 5.6 nH,S ,1005 ,R/TP , 1005GC2T5N6S00
C1 1 4 CAP ,CHIP, MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C11 5 CA P ,CE RA MIC,CHIP ECCH0000143 1 nF,50V, K,X7R,HD,1005,R/TP MCH1 5 5 CN10 2K K
C11 6 CA P ,CE RA MIC,CHIP ECCH0000110 10 pF,50V,D,NP0, TC,1005, R/TP MCH155A100D
C11 7 CA P ,C E RA MIC, CHIP ECCH0005603 2.2 uF,10V , K ,X5R , TC ,1608 , R/TP GRM39X5R225K10
C1 2 0 CAP ,CHIP ,MAKER ECZH0004402 100000 pF,16V ,Z ,X7R ,TC ,1005 ,R/TP MCH1 53 C10 4Z K
C1 2 1 CAP ,CHIP ,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C1 2 2 CAP ,CHIP ,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C1 2 4 CAP ,CHIP ,MAKER ECZH0000824 20 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H200JT
C1 2 5 CAP ,CHIP ,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C126 INDUCTOR,CHIP ELCH0001416 2.7 nH,S ,1005 ,R/TP ,PBFREE LL1005-FHL2N7S
C12 7 CA P ,C E RA MIC, CHIP ECCH0005603 2.2 uF,10V , K ,X5R , TC ,1608 , R/TP GRM39X5R225K10
C1 2 8 CAP ,CHIP ,MAKER ECZH0001002 0.5 pF,50V ,B ,NP0 ,TC ,1005 ,R/TP C1005CH1H0R5BB
C129 INDUCTOR,CHIP ELCH0001411 1.2 nH,S ,1005 ,R/TP ,PBFREE LL1005-FHL1N2S
C13 3 CA P ,C E RA MIC, CHIP ECCH0000112 15 pF,50V,J, NP0,TC,1005,R/TP MCH1 5 5C1 50 J
C1 3 4 CAP ,CHIP ,MAKER ECZH0000844 68 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H680JT
C13 5 CA P ,C E RA MIC, CHIP ECCH0009103 100 pF,50V ,J , X7R ,TC ,0603 ,R/TP C0603C0G1H101JT
C13 6 CA P ,C E RA MIC, CHIP ECCH0009103 100 pF,50V ,J , X7R ,TC ,0603 ,R/TP C0603C0G1H101JT
C13 7 CA P ,C E RA MIC, CHIP ECCH0009103 100 pF,50V ,J , X7R ,TC ,0603 ,R/TP C0603C0G1H101JT
C1 3 8 CAP ,CHIP ,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C13 9 CA P ,C E RA MIC, CHIP ECCH0000120 39 pF,50V,J, NP0,TC,1005,R/TP MCH155A390J
C14 1 CA P ,C E RA MIC, CHIP ECCH0000112 15 pF,50V,J, NP0,TC,1005,R/TP MCH1 5 5C1 50 J
C1 4 2 CAP ,CHIP ,MAKER ECZH0001316 470 pF,50V ,J ,NP0 ,TC ,1608 ,R/TP C1608C0G1H471JT
C14 3 CA P ,C E RA MIC, CHIP ECCH0000110 10 pF,50V,D,NP0,TC,1005,R/ TP MCH155A100D
C14 4 CA P ,C E RA MIC, CHIP ECCH0000198 2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP CL05A225MQ5 NNNC
C145 INDUCTOR,CHIP ELCH0001409 10 nH,J ,1005 ,R/TP ,PBFREE LL1005-FHL10NJ
C1 4 6 CAP ,CHIP ,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C1 4 7 CAP ,CHIP ,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C1 4 8 CAP ,CHIP ,MAKER ECZH0000841 56 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H560JT
C14 9 CA P ,C E RA MIC, CHIP ECCH0000122 47 pF,50V,J, NP0,TC,1005,R/TP MCH155A470JK
C1 5 0 CAP ,CHIP ,MAKER ECZH0004402 100000 pF,16V ,Z ,X7R ,TC ,1005 ,R/TP MCH1 53 C10 4Z K
C15 1 CA P ,C E RA MIC, CHIP ECCH0000198 2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP CL05A225MQ5 NNNC
C1 5 2 CAP ,CHIP ,MAKER ECZH0004402 100000 pF,16V ,Z ,X7R ,TC ,1005 ,R/TP MCH1 53 C10 4Z K
C1 5 3 CAP ,CHIP ,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C1 5 4 CAP ,CHIP ,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C15 5 CA P ,C E RA MIC, CHIP ECCH0000127 82 pF,50V,J, NP0,TC,1005,R/TP MCH155A820J
C15 6 CA P ,C E RA MIC, CHIP ECCH0000127 82 pF,50V,J, NP0,TC,1005,R/TP MCH155A820J
C1 5 7 CAP ,CHIP ,MAKER ECZH0004402 100000 pF,16V ,Z ,X7R ,TC ,1005 ,R/TP MCH1 53 C10 4Z K
C15 8 CA P ,C E RA MIC, CHIP ECCH0000143 1 nF,50V,K, X7R,HD,1005,R/TP MCH1 5 5 CN10 2K K
C15 9 CA P ,C E RA MIC, CHIP ECCH0000701 1.2 pF,50V , C ,NP0 , TC ,1005 , R/TP C1005C0G1H1R2CT
YWZVYZ\
203/235
