LG VX8560 - Page 110

LG Electronics Inc.
VX8560
Test point
Test point
1
TP1
C703
+2.8V_LCD
2
TP2
C708
LCD_RESET/
TP3
F701
LCD_WE/,CS/
TP4
F702
LCD_D[0]~[3]
TP5
F703
LCD_D[4]~[7]
TP6
F704
LCD_D[8]~[11]
TP7
F705
LCD_D[12]~[15]
F701
F702
F703
F704
F705
LCD_ID
SLCD_CS/
MLCD_CS/
LCD_WE/
LCD_D[0]
LCD_D[1]
LCD_D[2]
LCD_D[3]
LCD_D[4]
LCD_D[5]
LCD_D[6]
LCD_D[7]
LCD_D[8]
LCD_D[9]
LCD_D[10]
LCD_D[11]
LCD_D[12]
LCD_D[13]
LCD_D[14]
LCD_D[15]
XXWVYZ\
110/235
