LG VX8560 - Page 3

LG Electronics Inc.
VX8560
Table of Contents
General Introduction……………………………………………………………………………...4
CHAPTER 1. System Introduction
1. CDMA Abstract…….………………………………………………………………….…….…..5
2. Features and Advantages of CDMA Mobile Phone…………........................................6
3. Structure and Functions of Dual-band CDMA Mobile Phone……………………….….9
4. Specification……………………………………………………………………………………10
5. Installation………………………………………………………………………………………15
CHPATER 2. NAM Input Method
1. NAM Program Method and Telephone Number Inputting Method……………………17
CHAPTER 3. Circuit Description
1. RF Transmit/Receive Part……………………………………………………………….……31
2. Digital/Voice Processing Part……………………………………………………………….42
CHAPTER 4. Trouble Shooting
4.1. RX PART TROUBLE....…………………………………………………………………...48
4.2. LOGIC PART TROUBLE………………………………………………………………….94
CHAPTER 5. Safety………………………………………………………………..………162
CHAPTER 6. Glossary………………………………………………………………….…165
APPENDIX
1. Block Diagram ………………………………………………………………………178
2. Circuit diagram……………………………………………………………………...179
3. Component Layout…………………………………………………………………190
4. Assembly and Disassembly diagram…………………………………………...199
5. Part List………………………………………………………………………………202
6. BGA PIN MAP……………………………………………………………………….215
7. Accessories…………………………………………………………………………222
- AC adaptor……………………………………………………………………..223
- Cigar Light Charger…………………………………………………………..230
- USB Cable……………………………………………………………………...233
3/235
