1.4 Description of Frequency Synthesizer Circuit
1.4.1 Voltage Control Temperature Compensation Crystal Oscillator (VCTCXO, X101)
The temperature variation of mobile phone can be compensated by TCXO. The reference frequency of a mobile
phone is -30~+85 qC. The receives frequency tuning signals called TRK_LO_ADJ from QSC6055 as 0.5V~2.5V DC
via R and C filter in order to generate the reference frequency of 19.2MHz and input it into the frequency synthesizer
of UHF band. Frequency stability depending on temperature is ±2.0 ppm.
