Checking Flow
Checking Flow
Waveform
Waveform
Figure 4.1.1 (a)
Figure 4.1.1 (b)
Check X101 pin3
Is it 19.2MHz? (Refer to
figure 4.1.1 (a))
NO
Start
Replace Main B /D
VCTCXO circuit is Ok . See next page
to check control signal .
The Problem may be Logic part
Referto Logic troubleshoot
YES
NO
NO
Check X101 pin4
Is it 2.8V? (Refer to
figure 4.1.1 (b))
Replace X101 and then check C115 , R105 .
YES
Is it similar?
VCTCXO circuit is Ok . See next page
to check control signal .
YES
