LG VX8560 - Page 57

LG Electronics Inc.
VX8560
Test Point
Test Point
4.1.2 PCS Rx
Checking Flow
Checking Flow
Mobile S/W
Quintplexer
VCTCXO
QSC6075
1. Check
DC Power Supply circuit
2. Check
VCTCXO
Rx TEST SETUP (HHP)
- Test Channel: 675
-TestBand:USPCS
- SID: 4182
- Sect or Power: -30 dBm Spectrum An alyzer Setting
Oscilloscope Setting
Start
3. Check
RF Signal path
Redownload S
/
W
,
Cal
\^VYZ\
57/235
