LG W5-2 - Specifications

Appendix 73
Appendix
6
Specifications
General
Power requirements Refer to main label on the bottom panel.
Power consumption
Refer to main label on the bottom panel.
Networked standby : 0.5 W (If all network ports are activated.)
Dimensions (W x H x D) Approx. 410 mm x 55 mm X 260 mm
Net Weight (Approx.) 2.7 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Inputs/Outputs
HDMI IN/OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
ANALOG AUDIO IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplier
Power output (4 Ω/ 3 Ω), (RMS), THD 10 %
Total 1200 W
Front 194 W x 2
Center 194 W
Rear 194 W x 2
Sub-Woofer 230 W (Passive)
System
Laser Semiconductor laser
wavelength 405 nm / 650 nm
Signal system Standard PAL/NTSC color TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna)
Integrated IEEE 802.11b/g/n (2.4 GHz bands) wireless networking
access
Bus Power Supply (USB) 5 V
0
500 mA
