LG WD-14316RD Service Manual

20
NO
YES
NO
NO
YES
NO
YES
YES
NO
NO
YES
YES
YES
NO
NO
NO
YES
MAX
max
M
A
X
Detergent
for wash
Fabric
softener
Liquid
Bleach
Is water supply shut-off?
Is the tap opened?
When you press both Wash/Rinse button and
Spin Speed button simultaneously, is the water
level frequency below 240?
Is the inlet valve filter clogged?
Is resistance between each terminal of INLET
VALVE ASSEMBLY is 0.8~1.2
kΩ ?
Verify the voltage of the inlet valve connector is
120 V AC.
(Refer to 7-2 QC TEST MODE)
Is water supplied?
Are replaceptacles correctly connected to the
terminals of the INLET VALVE ASSEMBLY?
Is detergent put in the correct compartment of
the dispenser?
Is the detergent caked or hardened?
Open the tap.
Check the AIR CHAMBER
and the tube (clogged).
Clean the filter.
Replace the INLET VALVE
ASSEMBLY.
Check electrical connection.
Replace the MAIN PWB
ASSEMBLY.
Refer to
NO WATER SUPPLY
Check the wiring.
Put the detergent in the
correct position
MAIN WASH
: Detergent
Clean the dispenser.
NO WATER SUPPLY
DETERGENT DOES NOT FLOW IN
