LG ( 6023C / 8023C / 1023C) SUPER-SLIM WASHING MACHINES
Page 4
6. Power Chord
6.1. Type : 3*1.5 mm
2
copper conductor
6.2. Isolation : TS 936 FVV-n cable
6.3. Plug : Earthed, PVC injection
6.4. Length (mm) : 1700
7. MOTOR
7.1. Type : Mono phase, UM / AC
7.2. Power consumption (W) : 250 / 730 (wash / spin)
7.3. Speed (wash) (RPM) : 8200
7.4. Pulley diameter (mm) : 18.8
7.5. Isolation : Rotor class F ; Stator class F
7.6. Speed control : Electronic speed control
8. Pump
8.1. Power (W) : 34
8.2. Flow Rate (It/min) : 12-17
8.3. Pumping Height (m) : 1
9. Heater (W) : 1450 over heat protected type
10. Water Inlet (Cold) : Triple valve
11. Body
11.1. Material : Steel sheet
11.2. Coating : Acrylic, alkali resistant oven paint
12. Drum
12.1. Material : Stainless Steel
12.2. Volume (lit) : 31
12.3. Washing rate (RPM) : 50 ±2
12.4. Spinning rate (RPM) : 600 / 800 / 1000
12.5. Front cover hole diameter (mm) : 300
To Next Page
