LG ( 6023C / 8023C / 1023C) SUPER-SLIM WASHING MACHINES
Page 5
13. Tub
13.1. Material : %20 Talk reinforced PPTV20
13.2. Volume (lit) : 40
14. Damping System
14.1. Spring (Qty.) : 2
14.2. Frictional damper (Qty) : 2
14.3. Counter weight (Qty) : 3
14.3.1. Material : High density concrete
14.3.2. Weight (1pcs Top/ 2pcs Bottom) (Kg) : 22 (11,4 Top / 3,9 and 6,8 Bottom)
15. Control System
15.1. Controller : 220/230 V, 50 Hz.
15.1.1. Display Board : 26 LED ; 7 switches ; 1 Program Dial
1 7segment Display
15.1.2. Main Board : Program and motor controls
15.2. Thermostat - NTC : Tn-60C
15.3. Solenoid valve operating pressure : 0.3-10 Bars
15.4. Water pressure sensor : Output-kHz
15.5. Wash Programs (Qty) : 6(Cotton, Synthetic, Delicate, Hand,
Wool, Quick, Rinse+Spin, Spin, Pump)
15.6. Options (Qty) : 4 (Bio, ECO, Rinse plus, PreWash)
15.7. Selections (Qty) : 4 (TimeDelay, Easy Iron, Spin, Temp.)
