3
9
Water Guide
Fixing Bolt
Hall Sensor
Stator Housing
6) Replacement of Rotor & Stator
Disassemble rotor n
ut with bo
x
er(M18) or spaner
.
(
In assembled, the f
orce is ov
er than 200kgf
.cm)
Disassemble rotor
, pull out the rotor as shown the
figure.
Disconnect fixing screw and disassemb
le the w
ater
guide.
Bef
ore disassemble stator
,disconnect the hall sensor
and stator housing.
39
41
