37
Open the door.
Unscrew the 7 screws from the HINGE COVER.
Put a flat ( - ) screwdriver into the openng of the hinge,
and pull out the hinge cover.
Unscrew a screw from the lower side of door.
Disassemble the door upward.
DOOR
Open the door and disassemble the CLAMP
ASSEMBLY.
Unscrew the 2 screws.
DOOR LOCK SWITCH ASSEMBLY
Be careful! The door is heavy.
NOTE
• Reconnect the connector after replacing the
DOOR SWITCH ASSEMBLY.
To Next Page
