LG WM2077CW Service Manual

44
REPLACEMENT PARTS LIST
CAUTION : Before replacing any part of these components
Read carefully the safety precautions in this manual
¡Æ NOTE : S(Safety Parts), AL(Alternative parts)
LG MODEL: WD-11270BD.ABWEEUS Run_Date : 2004-04-09
YOUR MODEL: WM2277HW SPECIFICATION: 120V 60Hz
S AL LOC DESCRIPTION PARTS No. Q'TY REMARKS
*001 MANUAL ASSEMBLY,OWNERS 3829ER3021Q 1
*002 BOX,CARTON 3890EZ3524A 1
*003 SPANNER 3W20018B 1
*004 MANUAL,SERVICE 3828ER3018Y 0
*005 MANUAL,OWNERS 3828ER3024X 0
A100 CABINET ASSEMBLY 3091ER0004A 1
A101 COVER,BACK 3808FR1202A 1
A102 BUSHING 4830ER3001A 1
A103 HOLDER 4930FR3151A 1
A104 BOLT ASSEMBLY 4011FR3159E 2
A105 BOLT ASSEMBLY 4011FR3159D 2
A110 TOP PLATE ASSEMBLY 3457ER1006C 1
A130 COVER,CABINET 3550ER0009B 1
A133 CLAMP ASSEMBLY 2W20017E 1
A140 HINGE ASSEMBLY 4775ER2002A 1
A150 DOOR ASSEMBLY 3581ER1008A 1
A151 DOOR FRAME,OUTER 3212ER1023A 1
A152 DOOR FRAME,INNER 3212ER1016A 1
A153 HANDLE 3650ER2004A 1
A155 HANDLE 3650FA3488M 4
A200 BASE ASSEMBLY,CABINET 3041ER0001C 1
A220 LEG ASSEMBLY 4779ER3002A 4
A275 HOSE,INLET 5215FD3715G 1
A276 HOSE,INLET 5215FD3715H 1
A300 CASE 3110ER2003A 1
A303 CAP,COVER 5006FR3146D 1
A310 CAP,COVER 5006ER2003A 1
¡
A410 SWITCH ASSEMBLY,SENSOR SWITCH 6600FA1704X 1
¡ A430 POWER CORD ASSEMBLY 6411ER1005A 1
¡ A440 SWITCH ASSEMBLY,DOOR 6601ER1004C 1
¡ A450 PWB(PCB) ASSEMBLY,MAIN 6871EC1087C 1
A455 COVER,PROTECT 3550ER1020A 1
A485 FILTER ASSEMBLY(CIRC) 6201EC1004U 1
A490 BRACKET ASSEMBLY 4811ER3001A 1
A495 SENSOR ASSEMBLY 6501FA2462C 1
¡ F110 PWB(PCB) ASSEMBLY,DISPLAY 6871EC1116A 1
¡ F120 HARNESS,PWB 6877ER1023C 1
F130 CABLE,FLAT 6850EC2001A 1
¡ F140 HARNESS,MOTOR 6877ER1016B 1
¡ F141 HARNESS,MOTOR 6877ER3003B 1
¡ F160 VALVE ASSEMBLY,INLET 5221ER1003A 1
F170 VALVE ASSEMBLY,INLET 5220FR2006H 1
¡ F210 PANEL ASSEMBLY,CONTROL 3721ER1126A 1
F215 KNOB ASSEMBLY 4941ER3002A 1
F220 PANEL ASSEMBLY,DRAWER 3721ER1073D 1
F225 CAP,SOFTENER 5006ER3014B 1
F226 CAP,SIPHONE 5006ER3018A 1
F227 BOX ASSEMBLY,DETERGENT 3891ER2003A 1
F300 DISPENSER ASSEMBLY 4925ER1015B 1
F310 BELLOWS 4738ER1004B 1
F315 BELLOWS 4738ER2002A 1
F321 HOSE,INLET 5214ER4001A 1
F322 HOSE,INLET 5214ER4001B 2
F323 HOSE,INLET 5214ER4001J 1
