LG WM2077CW Service Manual

45
LG MODEL: WD-11270BD.ABWEEUS Run_Date : 2004-04-09
YOUR MODEL: WM2277HW SPECIFICATION: 120V 60Hz
S AL LOC DESCRIPTION PARTS No. Q'TY REMARKS
F430 HOSE ASSEMBLY,DRAIN 5215ER2002G 1
F431 CONNECTOR (MECH),DRAIN HOSE 4932FR3156A 1
F435 HOSE,DRAIN 5214FD3663E 1
F436 HOSE,INLET 5214FR4125S 1
F440 HOSE,PUMP 5214FR3188K 1
F441 CLAMP 4861FR3068C 3
F461 CLAMP 4861FR3068E 1
F463 CLAMP 4860FR3092D 2
F464 CLAMP 4860FR3092C 1
K101 TUB,OUTER 3044ER0003A 1
K105 TUB ASSEMBLY,OUTER[SUB4] 3045ER0008F 1
K110 TUB ASSEMBLY,INNER[DRUM] 3045ER1006A 1
K111 LIFTER ASSEMBLY 4433ER1001A 3
K115 SPIDER 4434ER0001A 1
K121 BEARING,BALL 4280FR4048D 1
K122 BEARING,BALL 4280FR4048E 1
K123 BOLT ASSEMBLY 4040FR4051B 1
K125 SEAL 4036ER2004A 1
K140 COVER ASSEMBLY,TUB 3551ER0003G 1
K141 SEAL 4036ER4001B 1
K143 SCREW,DRAWING 1SZZFA4362C 16
K310 THERMISTOR ASSEMBLY 6322FR2046F 1
K320 HEATER ASSEMBLY 5301FR1158J 1
K340 MOTOR ASSEMBLY,PUMP 4681EA2001D 1
K343 CLAMP 4860FR3092C 1
K344 CASING,PUMP 3108ER1001A 1
K345 MOTOR ASSEMBLY,PUMP 4681EA2001C 1
K346 FILTER(MECH) 5230ER3002A 1
K350 STATOR ASSEMBLY 4417FA1994G 1
K360 ROTOR ASSEMBLY 4413EA1002B 1
K410 SPRING,HINGE 4970FR2084P 2
K411 HOLDER 4930FR3040A 2
K510 GASKET 4986ER0004A 1
K520 BELLOWS 4738ER1002A 1
K530 CLAMP ASSEMBLY 4861ER2001D 1
K531 CLAMP 4861FR3068E 2
K540 CHAMBER,AIR 3504ER3002A 1
K550 HOSE,INLET 5214FR4125Y 1
K610 DAMPER ASSEMBLY,FRICTION 4901ER2002B 3
K611 HINGE 4774FR3118B 6
