LG WM3677HW Service Manual

3
1. SPECIFICATIONS
ITEM WM3677HW WD-12270RD WD-13276RD / WD-14276RD
COLOR BLUE WHITE TITANIUM
POWER SUPPLY AC 120 V, 60 Hz AC 120-127V, 60Hz
PRODUCT WEIGHT 201 lbs. (91 kg)
WASHING 280 W
DRAIN MOTOR 80 W
FAN MOTOR 25 W
DRY HEATER 1200 W
WASH HEATER 1000 W
WASH 42 rpm
SPIN
0-1100 rpm
CYCLES 7
WASH/RINSE TEMPERATURES 5
SPIN SPEEDS 5
OPTIONS
Prewash, Stain Cycle, Quick Cycle, Extra Rinse, Rinse+Spin
WASH/DRY PROGRAM Sanitary, Cotton/Towels, Normal, Perm Press, Speed Wash
CUSTOM PROGRAM Incorporated
WATER CIRCULATION Incorporated
OPERATIONAL WATER PRESSURE 4.5
-
145 psi (30-1000 kPa)
CONTROL TYPE Electronic
WASH CAPACITY
3.22 cu. ft (3.72 cu. ft. IEC)
DRY CAPACITY
Max. 11 lbs (5 kg)
DIMENSIONS
27” (W) X 29
3
/
4
” (D) X 38
11
/
16
” (H), 50
13
/
16
” (D, door open) 686mm(W)x767mm(D)x982mm(H), 1291mm(D) (D, door open)
DELAY WASH up to 12 hours
DOOR SWITCH TYPE PTC + Solenoid
WATER LEVEL 10 steps (by sensor)
LAUNDRY LOAD SENSING Incorporated
ERROR DIAGNOSIS Incorporated
AUTO POWER OFF Incorporated
CHILD LOCK Incorporated
ELECTRIC POWER
CONSUMTION
REVOLUTION SPEED
12 kg [WD-12270RD]
13 kg [WD-13276RD]
14 kg (30.86 lbs) [WD-14276RD]
8 kg [WD-12270RD]
8 kg [WD-13276RD]
8 kg (17.64 lbs) [WD-14276RD]
