MICRO Hi-Fi SYSTEM ] USER GUIDE
9
Troubleshooting
Designs and specifications are subject to change without notice.
Symptom Cause Correction
Specifications
General
Net Weight 1.5 kg
External dimensions (WxHxD) 150 x 150 x 205 mm
Tuner
FM Tuning Range 87.5 - 108.0 MHz or 65 - 74 MHz,
87.5 - 108.0 MHz
AM Tuning Range - OPTIONAL
522 - 1620 kHz or 520 - 1720 kHz
Amplifier
Output Power 5 W + 5 W (T.H.D 10 %)
Frequency Response 30 - 20000 Hz
Signal-to-noise ratio 75 dB
CD
Frequency response 40 - 20000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 75 dB
Speakers (XAS12F)
Type 1 Way 1 Speaker
Impedance 6 Ω
Frequency Response 100 - 17000 Hz
Sound Pressure Level 84 dB/W (1m)
Rated Input Power 5 W
Max. Input Power 10 W
Net Dimensions (WxHxD) 150 x 150 x 150 mm
Net Weight (1EA) 0.99 kg
No power.
No sound.
The unit does not
start playback.
The remote
control does not
work properly.
• The power cord is disconnected.
• The power of the external source
equipment is turned off.
• The speaker cable is connected
to a wrong position.
• An unplayable disc is inserted.
• The disc is placed upside down.
• The disc is not placed within the
guide.
• The disc is dirty.
• The remote control is not pointed
at the remote sensor of the unit.
• The remote control is too far from
the unit.
• There is an obstacle in the path
of the remote control and the unit.
• The battery in the remote control
is exhausted.
• Plug the power cord into the wall
outlet securely.
• Switch on the external source
equipment.
• Set the speaker cable to the cor-
rect position, then turn on the unit
again by pressing POWER.
• Insert a playable disc.
• Place the disc with the playback
side down.
• Place the disc on the disc tray
correctly inside the guide.
• Clean the disc.
• Point the remote control at the
remote sensor of the unit.
• Operate the remote control within
about 23 ft (7 m).
• Remove the obstacle.
• Replace the battery with new
one.
