Operation Manual of Elevating Work Platform
80
Traveling speed of machine
(folding status) (km/h)
3.5
Traveling speed of machine (lifting
status) (km/h)
0.8
Lifting/lowering speed (S)
16/28
Minimum turning radius (m)
1.72
Theoretical gradeability
25%
Overall length (m)
(with ladder/without ladder)
1.86/1.68
Overall width（m）
0.76
Tyre size (diameter×width)
323×100
Dimension of working platform
(L×W) (m)
1.63×0.74
Wheel tread (mm)
660
Wheelbase (front/rear) (mm)
1350
Ground clearance (folding /lifting
status) (mm)
80/20
Overall height (m) (Folding without
enclosure/Folding)
2.14/1.84
Overall weight (kg)
1610
Hoisting
Motor
Rated Power（KW）
3.3
Battery
Output Voltage(V)
6
Capacity (AH)
25A/447;75A/115
Charger
Nominal AC Intput
Voltage(V)
100-240VAC
Maximum DC
Output Current(A)
30
Nominal DC Output
Voltage(V)
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
< 70dBA
Type
Open-type system
Main pump
Gear Pump
System pressure (MPa)
21
Hydraulic oil
9.5L
Ground bearing information
Maximum wheel load
600Kg
Tire contact pressure
1074.83Kpa
Ground pressure
14.30Kpa
Table 22-AS0607WE Operating Specifications
Model
AS0607WE
Item
Parameter
Maximum number of worker
2
Maximum working height (m)
7.8
Maximum height of platform (m)
5.8
Extending size of platform (m)
0.9
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Braking distance
500±150
Maximum allowed wind
speed(m/s)
12.5
Traveling speed of machine
(folding status) (km/h)
4
Traveling speed of machine (lifting
status) (km/h)
0.8
Lifting/lowering speed (S)
16/28
Minimum turning radius (m)
1.75
Theoretical gradeability
25%
Overall length (m)
(with ladder/without ladder)
1.86/1.68
Overall width（m）
0.81
Tyre size (diameter×width)
323×100
Dimension of working platform
(L×W) (m)
1.63×0.74
Wheel tread (mm)
710
Wheelbase (front/rear) (mm)
1350
Ground clearance (folding /lifting
status) (mm)
80/20
Overall height (m) (Folding without
2.14/1.84
