Section 3
3-42 Setup and Operation
File Header
The file header is output each time the Start button is pressed and can contain a time stamp
(derived from the computer's system time), calibration zero and span values, and user-entered
remarks.
Destination
Enter a file name for the output file; the extension .TXT will be added automatically (although
no extension is required). Click on the Browse button to change drives and/or directories.
Delimiter
Data can be output using tab- or space-delimited text.
Log Values
Click on the 'Log Values' check boxes to choose the variables to be output. ‘Relative Time’ is
seconds since the Start button was pressed.
Strip Charts Page - Viewing Data Output
The Strip Chart page allows real time graphics display of one or two variables plotted against
time. The Y-Axes (left and right) display the value chosen in the respective pull-down menus
against time on the X-Axis. Choose the value in the pull-down menu, and enter values for the
Y-Axis maximum and minimum. Choose the X-Axis maximum value, and select the seconds
or minutes button. The scrolling buttons determine the rate of refresh of the strip chart;
