Lian-Li LANCOOL II MESH User Manual

- 2 -
* 零件盒部品一覽表
* Hardware list
* Liste des pièces
* Hardwareliste
* Lista de materiales
*
Screws
for 3.5" HDD mount
Screws
for mother board
2.5" SSD mount
and
Screws
for PSU mounting
e
f
4 pcs
29 pcs
a
16 pcs
10 pcs
d
Cable ties
for cable management
Screws /
for 2.5" SSD mount
Anti-vibration rings
12 pcs
c
1 piece
Tool
for Stand off bolt
Exceeded quantity are spare parts.
多餘的零件數量是備品.
Zusätzliche Teile können als Ersatzteile verwendet werden.
Les pièces supplémentaires sont des pièces de rechange.
Exceeded quantity are spare parts.
8 pcs
Screws
for 120 mm fan
g
2 pcs
Velcro
for cable management
h
* The fan is installed in the middle of the top cover
* 風扇安裝在上蓋的中間
* Le ventilateur est installé au milieu du capot supérieur
* Der Lüfter befindet sich in der Mitte der oberen Abdeckung
* El ventilador está instalado en el medio de la cubierta superior
* ファンはトップカバーの中央に取り付けられています

Lian-Li LANCOOL II MESH Specifications

General

Type	PC
Material	SGCC, Tempered glass
Form factor	Tower
Side window	Yes
Product color	Black
Maximum PSU length	210 mm
Number of 2.5\" bays	6
Number of 3.5\" bays	3
Number of 5.25\" bays	0
Maximum CPU cooler height	176 mm
Number of expansion slots	7
Maximum graphics card length	384 mm
Number of storage drives supported	9
Supported motherboard form factors	ATX, EATX, ITX, Micro ATX
Rear fans installed	1x 120 mm
Top fans diameters supported	120, 140 mm
Rear fans diameters supported	120 mm
Number of top fans supported (max)	2
Number of rear fans supported (max)	1
Supported HDD sizes	2.5, 3.5 \
Power supply included	No
Power supply location	Bottom
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
