3. MySignals’s Hardware Setup
All the items included in the basic kit of MySignals are in their specic compartiments in MySignals briefcase.
Figure : Mysignals briefcase
3.1. Power Supply
General power supply
Operating Current 2 A
Operating Voltage 5V
Input Voltage (recommended) 12V
Input Voltage (limit) 10-20V
Specic power supply
DC Current per I/O Pin 20 mA [Max]
DC Current for 3.3V 1 A [Max]
DC Current for 5V 1 A [Max]
DC Current for 4 V Pin 2 A [Max]
Plug in /out the power supply adapter included with MySignals to turn ON or OFF the device. Make sure that the power adapter
is indoors.
Plug it into the corresponding power supply connector. At Libelium we oer equipment for operating at 12V, do not use other
power supplies.
You can see all the information about the power supply in the label included in MySignals device.
