4 Humitemp sensor
The Humitemp senor is a combined temperature- and humidity-sensor. If
installed the Microface will use the values of the Humitemp sensor for all
control operations. The Humitemp sensor is connected to the Microface board
by the Hirobus-cable (max. length: 25 m).
The Humitemp sensor is an air-sensor and only used for air-conditioning units.
Fig. 4 -1 Humitemp sensor
The address-switches / jumpers on the rear of the Humitemp sensor allow to
set different functions to the sensor.
5 List of Microface spare parts
Description Code
Microface (complete)
275297
Display
275098
Alarmcard
275148
Probe airflow PTC
275184
Humitemp Sensor
275181
Plastic Distance Holder
(4 no. of each code required)
271286
271287
271288
Fig. 4 -2 Humitemp jumper (set to control sensor)
