Liebert Prop Fan Condensing Unit - Electrical Data

Installation
23
Table 17 Electrical data—High ambient models (105°F/41°C) 60Hz
Model #
Nominal
Capacity,
Tons
* Electrical
Characteristic
Input Voltage-Phase
208/230-1 208/230-3 460-3 575-3
27 2
FLA 15.4 — — —
WSA 18.4 — — —
OPD 30 — — —
37 3
FLA 20.5 15.4 8.1 5.8
WSA 24.8 18.4 9.7 7.0
OPD 40 30 15 15
42 3.5
FLA — 17.0 8.1 6.0
WSA — 20.4 9.7 7.2
OPD — 30 15 15
67 5
FLA — 24.2 11.7 9.3
WSA — 29.4 14.2 11.3
OPD — 50 20 15
* FLA = Full Load Amps
WSA = Wire Size Amps (minimum supply circuit current capacity)
OPD = Overcurrent Protection Device (fuse or circuit breaker)
Model # 14, 20 and 96 are not available in high ambient versions.
Table 18 Electrical data—Quiet-Line models (95°F/35°C) 60Hz
Model #
Nominal
Capacity
Tons
* Electrical
Characteristic
Input Voltage-Phase
208/230-1 208/230-3 460-3 575-3
27 2
FLA 12.9 — — —
WSA 15.9 — — —
OPD 25 — — —
37 3
FLA 18.0 12.9 7.1 —
WSA 22.3 15.9 8.7 —
OPD 35 25 15 —
42 3.5
FLA — 14.5 6.9 —
WSA — 17.9 8.5 —
OPD — 30 15 —
67 5
FLA — 22.5 10.9 8.3
WSA — 27.7 13.4 10.2
OPD — 45 20 15
* FLA = Full Load Amps
WSA = Wire Size Amps (minimum supply circuit current capacity)
OPD = Overcurrent Protection Device (fuse or circuit breaker)
Model # 14, 20 and 96 are not available in Quiet-Line versions.
Table 19 Electrical data—Standard sound and ambient models (95°F/35°C) 50Hz
Model #
Nominal
Capacity
Tons
* Electrical
Characteristic
Input Voltage-Phase
220-1 380/415-3
36 3 FLA 18.4 7.0
41 3.5 FLA — 8.5
66 5 FLA — 11.7
95 8 FLA — 18.1
* FLA = Full Load Amps
