What to do if LifeFitness Treadmill striding belt slips?
If the striding belt on your LifeFitness Treadmill slips during footfall, it may be due to the belt slipping on the front roller during the stall test. To fix this, check the striding belt and re-tension it as necessary.
What to do if LifeFitness Treadmill is making knocking sound coming from deck?
If your LifeFitness Treadmill is making a knocking sound coming from the deck, it may be due to life springs not positioned correctly or loose mounting hardware. To resolve this, reposition or tighten the life springs.
Why is my LifeFitness Treadmill maximum speed reduced?
A reduction in maximum speed on your LifeFitness Treadmill can occur due to several reasons. The user might be pushing the striding belt, in which case, instruct them not to do so in either direction. It could also be due to a wax system malfunction; inspect the spray pattern between 8" (200mm) and 16" (400mm), and if it's not correct, verify the wax nozzle is clean, the hoses are not kinked, the wax bag isn't empty, or the wax is not contaminated. Another cause may be a striding belt/deck malfunction, such as the deck laminate wearing through or the underside of the striding belt becoming glazed; in this case, replace both the belt and deck. Finally, an insufficient power source can cause this issue, so ensure the treadmill is plugged into a dedicated 20amp circuit.
What to do if I hear rubbing sound from underneath LifeFitness Treadmill?
If you hear a rubbing sound from underneath your LifeFitness Treadmill, it could be due to a couple of things. First, inspect underneath the striding belt and the machine for any foreign objects that may be stuck there, and remove any debris or objects that may be causing interference. Second, check the tinsel and reposition it on the outside of the striding belt if it's installed incorrectly.
Why is my LifeFitness Treadmill making a knocking sound at the rear?
A knocking sound at the rear of your LifeFitness Treadmill may be due to faulty rear roller bearings, in which case you should replace the rear roller assembly. Alternatively, it could be caused by wax build-up on the rear roller; try running the unit for 10 hours to break in the treadmill.
General| Running Area | 20" x 60" |
|---|---|
| Incline Range | 0% - 15% |
| Motor | 3.0 HP continuous duty AC motor |
| Heart Rate Monitoring | Yes (contact and telemetry) |
| Maximum User Weight | 400 lbs |
Explains how to use the manual and contact customer support.
Describes display consoles and control locations.
Guides on setting the treadmill's real-time clock.
Explains how to access diagnostic modes.
Quick reference for diagnostic test selections.
Lists the available system tests.
Introduces system information categories.
Lists system maintenance procedures.
Introduces system configuration areas.
Step-by-step guide to replace the belt and deck.
Guide to adjust the striding belt tracking.
Step-by-step guide to replace the drive motor.
Step-by-step guide to replace the motor controller.
Guide to clean the wax nozzle.
Details the display console PCB.
Details the motor controller PCB.
Details the power factor control PCB.
Details the wax lift PCB.
Details the smart stop PCB.
Provides the electronic block diagram.
Shows where to find model and serial numbers.
Parts identification for Model 9100.
Parts identification for Model 9500HR.
Parts identification for Model 9700HR.
Parts identification for Model 9700HR W/Incline.
Provides a preventive maintenance schedule.
Step-by-step guide for unpacking the treadmill.
Important safety instructions for installation.
Instructions for communicating via fax for parts or support.
