3 ASSEMBLY
3.1 TOOLS & HARDWARE
Identify the following components after unpacking your Lifecycle. The tools needed for assembly are included.
8
Tools Needed for Assembly:
• Metric Wrench Set
• Metric Allen Wrench Set
• Phillips Screwdriver
Item Quantity Description
1 2 50mm Button Head Screw
2 2 20mm Button Head Screw
3 2 100mm Hex Head Bolt
4 5 Thick Flat Washer - 16mm O.D.
5 2 60mm Hex Head Bolt
6 6 12mm Small Head Phillips Screw
7 4 Flat Washer - 12mm O.D.
8 3 Nylock Nut (on seat)
9 3 Flat Washer (on seat)
10 2 8mm Phillips Screw
11 2 6mm Phillips Screw
12 1 6mm Phillips Screw w/ Locking Compound
13 0 8mm Phillips Screw
14 4 15mm Button Head Screw
15 4 Flat Washer - 18mm O.D.
16 4 12mm Self-Tapping Screw
