LifeGear 75118 Inversion table - Step 9: Handlebar Installation

13
STEP 9:
Attach the top end of Handlebar (29) onto the Rear U-Frame (2) and Pivot Arm Ring (49) with one
M8x 23 Hex Head Bolt (38), one M8 Lock Nut (15), and two Ø 20xØ 8.5x1.5 Washers (13). Attach the
bottom end of the Handlebar (29) onto the Rear U-Frame (2) with one M8x38 Hex Head Bolt (43),
one M8 Lock Nut (15), and two Ø 20xØ 8.5x1.5 Washers (13). Repeat above same steps to attach the
other Handlebar (29) onto the Rear U-Frame (2) and Pivot Arm Ring (49).
13
15
29
43
13
13
15
38
13
2
49
