LifeSize Room 220 Installation Guide 25
IP Address Displays Invalid Value
After you complete the initial configuration, if the IP address that appears at the top of the
main screen displays an invalid value, one of the following conditions may exist:
Camera Issues
Video from the camera appears in a small window on the main screen of the user interface
above the Redial list. If no video from the camera appears, do the following:
• Ensure that the camera is properly connected to the LifeSize codec as described in
“Installing a LifeSize Room 220 System” on page 14.
• Verify that the blue LED on the front of the camera is lit and not blinking, indicating that
power is active.
• From the main screen of the user interface, press to access the System Menu.
Press to access page 2 of the System Information page. Ensure that the status of
the camera is Ready.
• Ensure that the primary input is set to the high definition camera. Press on the
remote control. If Primary Input : HD Camera does not appear at the top of the screen,
press to display the Primary Input selection dialog. Use the arrow keys on the
remote control to select the appropriate high definition camera and press OK.
Improving a Dim Image
If the image is too dim, you can adjust the HD Camera Brightness preference in User (or
Administrator) Preferences : Diagnostics : High Definition Camera.
Condition Resolution
The unit is configured to obtain an address
using DHCP and no DHCP server is
available.
Note: The DHCP client self-assigns an
address in the 169.254 class B network
and the red network symbol appears in
the status bar on the main screen.
Verify that the unit is plugged into a network that has a DHCP
server present.
Faulty Ethernet cable connection. Replace the Ethernet cable with a high quality cable.
The unit is configured to use a static IP
address, but no IP address has been
entered.
Identify and enter the necessary IP information if you disable
DHCP.
Network connection is unavailable.
A red network symbol appears in the
status bar on the main screen.
Inspect your network connection.
