4 LifeSize Room User Guide
3. Insert the codec into its stand by aligning the pin holes at the base. Secure the codec in
the stand by tightening the bolt on the bottom of the codec stand. Optional: Insert the
rubber feet on the bottom of the codec stand.
4. Insert the necessary cables into the back panel of the codec, using the plastic guide at
the bottom of the unit to keep all cables secure.
5. Insert the camera cable into the port on the rear side of the camera and plug the
opposite end into port marked with the camera 1 symbol on the back panel of the
codec.
6. Insert the video display cable into the port on the rear of your display and the opposite
end into the port marked with the display 1 symbol on the back panel of the codec.
Insert the display power cord into a power outlet on the wall.
7. Insert the network cable into the network port on the back panel of the codec; this port is
marked with the LAN symbol . Insert the opposite end of the network cable into a
network port on the wall.
8. Insert the phone cable into the port on the underside of the phone closest to the center;
this port is marked with the LAN symbol . The exterior port is reserved for future
use. Ensure the cables are secured into the guides to avoid damage to them. Insert the
opposite end of the phone cable into the back panel of the codec marked with the
LifeSize Phone symbol .
9. Insert the audio cable into the port on your display and the opposite end into the line out
port on the back panel of the codec marked with the symbol.
10. Insert the power cord into the power outlet marked on the back panel of
the codec (near the base) and the opposite end into a power outlet on the wall.
11. The camera initializes the first time it is connected to a codec; this process takes about
90 seconds. Do not disturb or disconnect the devices during this time as you may
damage the system.
12. The LifeSize Room system boots, and you are prompted to configure it the first time.
You can change preferences such as the display language, administrator password (for
accessing advanced preferences), locale data, dialing options, and network settings.
Note: For security reasons, LifeSize recommends you change the default
administrator password (1 2 3 4) during the initial configuration.
Once you have completed the initial configuration, you can then place calls, receive calls, or
configure additional preferences.
