LifeSize Room User Guide 19
Press Near a third time to remove the input selection from the screen. To select a far
side camera to control during a call, press the Far button twice and then press the
key to select the camera you wish to control.
4. Press the button to start the presentation.
Note: If one of the systems in a call does not support H.239, no second media channel
is established, and the button does not display. In this case, you must manually
invoke the presentation by selecting PC (or the desired input) as the primary input in
order to show the presentation.
5. Press the
button again to stop the presentation.
Note: You can change inputs at any time during a call. The far end can also start a
presentation, which halts the current presentation at the near end.
Using the Directory
The directory is H.350 compliant and provides a list of names and numbers from which you
can make calls. You can store up to 1000 entries in both an alphabetical and hierarchical
format.
To access the directory, press the button from the main screen. The directory is
comprised of local and corporate entries. The local directory is stored on the system and
includes modifiable entries. The corporate directory is read only and is automatically
populated.
If you leave the directory and return to it at a later time, you return to the same place at
which you left it. To move up one level, press the button.
To add an entry to the local directory follow these steps:
1. Using the arrow keys, navigate to the Add New Entry button and press OK.
The New Directory Entry screen displays.
2. Use the arrow keys to navigate through the screen and enter new data, including a
System Name and IP address or ISDN numbers.
a. Press OK to select a field and enter a value.
Note: If necessary, press the button to change the text entry mode for text fields.
b. After entering a value, press OK to exit an individual field.
