LifeSource UA-767 User Manual

AIR SOCKET
MEASUREMENT
IN PROGRESS
LOW BATTERY
DISPLAY
SYSTOLIC DISPLAY
DIASTOLIC
DISPLAY
START BUTTON
AIR CONNECTOR
CUFF
BATTERY COMPARTMENT
ADJUSTMENT SCREW
BLACK PROTECTION CAP
ON ADJUSTMENT SCREW
UA-767
DIGITAL
BLOOD
PRESSURE
MONITOR
SYSTOLIC
mmHg
DIASTOLIC
mmHg
PUL / min
240
210
180
150
PRESSURE
SWITCH
PULSE DISPLAY
MONITOR COMPONENTS
TUBE
TM
Display
Symbol
Recommended
Action
Remain still and refrain
from talking; measure-
ment in progress.
Replace all batteries
with new ones.
Check for air leakage;
make sure cuff tube is
properly connected to
monitor and exhaust
rate is in increments of
2 mmHg. to 5 mmHg
Try measurement again
and remain very still.
Make sure cuff tube is
properly connected to
monitor, cuff is securely
fastened and exhaust rate
is between 2 mmHg and
5 mmHg. Make sure air
connector is inserted
properly into tube
and monitor.
Condition/
Cause
Appears during measure-
ment; blinks and beeps
when pulse is detected.
Battery voltage is
too low for monitor
to work properly.
Appears when systolic
and diastolic measure-
ments are within 10
mmHg of each other.
Appears if pressure
value is unstable due
to movement during
reading.
Appears when pressure
value did not increase
during cuff inflation:
1) cuff is not fastened
2) air connector is
not connected properly.
MEASUREMENT IN
PROGRESS
LOW BATTERY
ERROR 2
ERROR 1
ERROR 3
MONITEUR
TUYAU DU
BRASSARD
WHAT DISPLAY SYMBOLS MEAN
?
3
4
?
?
LifeSource Health Line (Toll-Free): 1-888-726-9966 LifeSource Health Line (Toll-Free): 1-888-726-9966
?
START

LifeSource UA-767 Specifications

General

Model	UA-767
Category	Blood Pressure Monitor
Measurement Method	Oscillometric
Memory Capacity	60 readings
Display	LCD
Type	Upper Arm
Irregular Heartbeat Detection	Yes
Clinically Validated	Yes
Power Source	4 x AA batteries or AC adapter
Measurement Range (Pulse)	40-200 beats/minute
Accuracy (Blood Pressure)	±3 mmHg
Accuracy (Pulse)	+/- 5%
Weight	Approx. 340g (without batteries)
