6. Belt Tracking Adjustment:
This treadmill is designed to keep the belt reasonably centred while in use. It is normal for some belts to drift
near one side while the belt is running with no one on it. After a few minutes of use, the belt should have a
tendency to centre itself. If during use, the belt continues to move toward one side, adjustments are
necessary. The procedures are below:
1. Set speed at approximately 3.5km/h.
2. Check the side the belt shifts to.
If the belt shifts to right, tighten the right bolt and loosen the left bolt by using 6mm Allen Key, until the belt is
centred itself; If belt shifts to left, tighten the left bolt and loosen the right bolt by using a 6mm Allen Key, until
the belt is centred. When adjusting the belt using the 6 mm Allen Key, it is important to adjust the belt in half
turn increments. Over adjusting the belt can cause damage to the mat.
If belt drifts to the RIGHT If belt drifts to the LEFT
