4
1. Adjustable Wrench
2. One 60 lb. bag of sand
3. 7/16” Wrenches (2)
TOOLS AND MATERIALS REQUIRED FOR ASSEMBLY
(Not Included)
4. 3/4” Wrenches (2)
5. 3/8” Socket Wrench
6. Phillips Screwdriver
ID Part # Description Qty.
AA 1029635 Tube, Swaged 1
AB 1029636 Tube 1
AC 1029563 Net 1
AD 1029561 Weight Bag 2
Net Hardware (1029637)
NA BN00300 1/4”-20 Cap Nut 6
NB 1029478 1/4”-20 x 1 3/4” Hex Bolt 6
NC 1029479 1/4” Flat Washer 12
ND 1029560 Harness 1
NE 1031424 6 mm Screw 1
NF 1031444 1” Plug 2
NG 1028233 Bungee Cord 2
PARTS LIST
BEFORE BEGINNING ASSEMBLY
A. Keep the hardware bags and their contents separate. If any parts are
missing, call our Customer Service Department.
B. Test fit all Bolts by inserting them into their respective holes. If necessary,
carefully scrape away any excess powder coating buildup from inside
the holes. Do not scrape away all of the powder coating. Bare metal may
rust. You may need to pound some Bolts into place with a hammer or
mallet.
