Lifetime 2871 - Final Bench Assembly Steps; Position Upper Bench Assembly; Connect Bearing Arms

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
12
SEC
2
ConnectBearingArmstotheLeftandRightLegAssembliesusingthehardwareshown.
BAM
BAM
BAM
BAM
Usingatleasttwoadults,carefullylifttheUpperBenchAssemblyandsetitontheLegAssembly.
WARNING
DonotovertightentheCapNut.
SEC
2.3
SEC
2.4
BAM(x4)
7/16”
Note: The bearings are lubricated for life and require no
further lubrication.
!
2.
