Lifetime 2871 - Parts and Hardware Identification; Frame Assembly Hardware; Back & Seat Assembly Hardware

5
ID DESCRIPTION QTY
BAS RightLeg 1
BAT LeftLeg 1
BAU LegCrossSupport 2
BAV BearingArm 4
BAW RightArm 1
BAX LeftArm 1
BAY BackCrossSupport 1
BAZ SeatCrossSupport 1
BBA BenchBack 1
BBB BenchSeat 1
BACK & SEAT ASSEMBLY HARDWARE BAG [BCJ]
Partsshownareactualsize(unlessotherwisenoted)
FRAME ASSEMBLY HARDWARE BAG [BCI]
Partsshownareactualsize(unlessotherwisenoted)
BAL(x9)
PlasticScrew
BAM(x4)
1/4”-20NylockCapNut
BAM(x4)
1/4”NylockCapNut
BAN(x14)
M5x.8mmNylockNut
BAO(x1)
5mmAllenWrench(Included)
BCE(x8)
M5x.8mmx25mmPan-HeadScrew
BCF(x2)
M5x.8mmx33mmPan-HeadScrew
BCG(x4)
M5x.8mmx57mmPan-HeadScrew
HARDWARE IDENTIFIER
PARTS & HARDWARE LIST
ID DESCRIPTION QTY
BCI FRAME ASSEMBLY HARDWARE BAG
BCE M5x.8mmx25mmPan-HeadScrew 8
BCF M5x.8mmx33mmPan-HeadScrew 2
BCG M5x.8mmx57mmPan-HeadScrew 4
BAN M5x.8mmNylockNut 14
BAM 1/4NylockCapNut 4
BCJ BACK & SEAT ASSEMBLY HARDWARE BAG
BAM 1/4NylockCapNut 4
BAL PlasticScrew 9
BAO 5mmAllenWrench 1
