14
TOOLS AND HARDWARE REQUIRED
X SECTION 3 (CONTINUED)
• Secure with the hardware included.
ADV (x6)
AFE
AGF
ADV
ADV
ADV
ADV
ADV
ADV
• The fl at holes face away from the Gable.
• The fl at hole faces downward.
• Align the holes in the Lintel (AFE) with those in the
Entry Gable (AGF).
3.2
• If you have trouble with this section, follow the code below
to view a video on the assembly in this section.
http://go.lifetime.com/gableassembly7
3.1
