28
TOOLS AND HARDWARE REQUIRED
X SECTION 6 (CONTINUED)
AFX
AGR
AGR
45°
45°
• Attach an Outer Floor Panel (AGR) to the Inner Floor Panel.
6.1
6.2
• If you have trouble with this section, follow the code below
to view a video on how to assemble this section.
http://go.lifetime.com/rightdoorassembly7
LIFETIME
©
• Hold an Inner Floor Panel (AFX) at an angle and slide the tabs
along the edge underneath the other Outer Floor Panel (AGR).
The tabs interlock. Lay Panel down fl at.
To Next Page
