Lifetime 60231 - Page 50

50
TOOLS AND HARDWARE REQUIRED
X SECTION 9 (CONTINUED)
BFY (x5)
ADJ (x5)
BXZ (x10)
BYA
BYA
7/16 in/po
(11 mm)
• Place the Left Door Jamb (BYA) onto the edge of the left, front Corner Wall Panel. The Curved edge curves toward the
outside of the shed. Align the holes in the Jamb with those in the Corner Wall Panel. Secure the Jamb to the Panel
using the required hardware.
• Curved edge
BXZ
BXZ
BXZ
BXZ
ADJ
ADJ
BFY
BFY
9.2
Plastic
