78
TOOLS AND HARDWARE REQUIRED
X SECTION 13 (CONTINUED)
13.1
ACA
AEB
AAB
CVT
• Only after following the anchoring instructions, attach the Left Latch Bracket (CVT) to the Left Door using the
hardware provided. Only hand tighten the Nut at this point.
ACA (x1)
AEB (x1)
AAB (x1)
CVT (x1)
• If you have trouble with this section, follow the code below to view a video on the installation in this section.
http://go.lifetime.com/doorlatchslider
LIFETIME
©
