Lifetime 60231 - Page 83

83
TOOLS AND HARDWARE REQUIRED
X SECTION 13 (CONTINUED)
13.7
13.8
CHK (x1)
• Close both Doors and lock the Latch. Adjust the Left Latch Bracket so the Latch slides through freely.
CHK
• Insert one (1) Self-Drilling/Self-Tapping Screw (CHK) through the hole in the Left Latch Bracket to secure it in place.
