Lifetime 6417 - Page 13

13
71 11/16”
79 1/2”
20 1/8”
PARTS & HARDWARE IDENTIFIER
AGB (x1)
Domed Skylight
AGQY
Center Roof Panel
AFL (x14)
Roof Support Strip
AFYY
Center Roof Cap
28 7/8”
AHGY
Window Frame
AHFY
Window
BOX 2
AFP (x4)
Truss Support Strip
Parts shown at 4% of actual size
Parts shown at 8% of actual size
Parts shown at 8% of actual size
METAL PARTS KIT 1 [BNL]
METAL PARTS KIT 2 [BNK]
Part shown at 8% of actual size
AFH (x4)
5SVTT(VUUFS$IBOOFM
AFGY
Roof Truss Brace
79 1/2”
AFQ (x4)
Wall Support Channel
